Save resources and time by verifying the quality of automated welds in real time with the iShot® Weld-i® Series of cameras. The modular weld-monitoring cameras can be configured to obtain high-resolution video footage of virtually any welding process. The inspection systems combine these specially housed, high-resolution cameras with air or water-cooling capabilities to allow them to withstand the punishing environments of automated welding. Our Weld-i camera systems enable the user to record and view the electrode, arc, puddle, joint, and surrounding base material before, during, and after the welding process.
High-resolution color CCD camera with remote control of focus and iris.
Zoom in to view real time detailed color video images of your welding process.
With a dynamic-range of over 10,000,000:1, the zoom camera captures both arc and metal simultaneously. See the arc, electrode, puddle, joint & surrounding metal before, during & after the welding process. No filters needed!
Inspect the interior of orbital pipe welds thoroughly and efficiently with the iShot® Weld-i® flexible and non-articulating video borescope weld inspection system The OD measures 6mm x 7.5 meters in length.
View high quality video and capture still images of pipe welds with the Orbital Weld Videoscpe.
View the arc, electrode, puddle, joint and surrounding metal before, during and after the welding process.
NEW! The iShot® PTZ-400 is a powerful Pan, Tilt, and Zoom Camera fitting through 4.0 inch (105mm) diameter opening and can turn to a right angle in 4 inch ID pipe. The total operating envelope from fixed mount 4.00 inch diameter x 8.00 cylinder and an overall height 8 inches. Equipped with Continuous 360 degree Pan, 110 degree tilt 10x optical zoom and day night function.
The iShot® PTZ-550 measures 5.5-inches (140 mm) in diameter with a total operating envelope from fixed mount 7.25 inch (184.2mm) sphere. Equipped with a 36x Optical Zoom, Auto Focus, and Image Stabilization provide sharp, high resolution video of hazardous and inaccessible areas.
10x zoom PTZ Camera system 4" OD x 8" in length with continuous 360° pan & 110° tilt.
36x zoom PTZ Camera system measuring 5.5" in diameter x 11" in length with continuous 360° pan & 245° tilt.
The iShot® HD W-Series of Waterproof cameras are the perfect solution for wet and submersed environments.
The submersible stainless steel color camera measures 1 inch in diameter and a length of 4 inches and features an integral cable with a length of 100 feet. The HD-SDI camera features include a 1920 x 1080 (1080p@30, 720p@60fps), 1/3 inch 2.1 megapixel CMOS sensor, digital day/night capabilities, on screen display with remote, and a 3.7mm megapixel board lens. 0.375" version coming soon!
Full HD 1" x 4" submersible color camera with an integral cable length of 100'.
9.52mm OD submersible camera, available FALL 2014.
The Sony FCB-EX2700 (40x), FCB-EX2400 (28x), FCB-EX2200 (18x) SD block cameras feature horizontal resolution of 670 TV lines, Super HAD CCD II image sensors for dark environments, Wide-D, Auto ICR, & Spherical Privacy Zone Masking.
The Sony FCB-EV7500 (30x) & FCB-EV7100 (10x) Enhanced Visibility HD block cameras use 1/2.8" Exmor CMOS image sensor supporting FULL HD for high-quality images. Using progressive scan, images with wide D range can be obtained with the newly developed image signal processor. FCB-EV5500 (30x) 720/60p.
Sony Enchanced Visibility Full HD 1920 x 1080 Cameras range from 10x to 30x zoom.
FCB-EX F Series features 960H CCD Sensor and up to 40x Zoom Cameras.
Toshiba introduces the IK-HD5H camera, the latest 3-CMOS camera innovation, a progressive-scan full-HD 1080p/1080i video camera featuring 3G-SDI, HD-SDI and DVI-D outputs and removable optical low pass filter (OLPF) for dual-mode imaging applications switchable between visible light and enhanced near-infrared visualization.
The Ultra compact, 3 CMOS, IK-4KH Ultra HD 3840 x 2160p, 59.94Hz camera designed for providing rich colors and incredibly sharp details in 4K. This remote-head power house will adapt to many color critical applications including broadcast, clinical and defense imaging.
1920 x 1080p, 3-CMOS HD Sensors, 2.1MP, Progressive Scan, 3G-SDI & DVI-D output.
Toshiba IK-4KH Ultra HD 3CMOS Camera with 1/2.9" Progressive Sensors, 3840 X 2160p/60 and 1,500 TV Lines.
iShot® XBlock® introduces the new 3G-SDI interface board for Sony FCB-EV7500 and Sony FCB-EV7100. Digital video output (3G-SDI SMPTE 424 M or HDSDI 292 M) via BNC to MCX connector. HD-SDI output is also avialable with the same board configuration for FCB EH Sony block cameras, FCB-EH6500, FCB-EH6300, FCB-EH3410. Depending on the camera model, component and SD Composite analog video outputs are avaiable. RS232 to/from TTL conversion for external control. The 3G-SDI board is available as a stand alone board, OEM integration kit, OEM Evaluation kit or as complete XBlock® Cameras integrating the Sony FCB-EV Series or FCB-EH Series.
3G-SDI interface board provides Full HD 1920 x 1080 camera control for Sony FCB EV Series of block cameras.
The New 3G-SDI XBlock camera with full HD 1920 x 1080 features Sony FCB-EV7500 in an indoor housing.
The Wohler VIS 350 PLUS System includes both a 1 inch and 1.5 inch detachable pan and tilt cameras with transmitter, aTFT monitor 7" with 6 ft. cable, and a 2 GB SD card for recording of pictures and video. The waterproof push camera allows the inspector to take a close look at pipes, air ducts, chimneys, vents, cracks, and welding seams. 4 system configurations available.
The Wohler VIS 400 features a 2 inch pan & tilt camera and is available with a 65 or 100 foot soft cable or a 100 foot push rod. Quality 7 inch TFT full color monitor for viewing and recording inspections with built in recording to an SD card. Mini USB out for pictiure download. 3 system configurations available.
1.5" OD Pan & Tilt push camera provides a close look at targets & waterproof up to 100'.
The 2" full color, pan & tilt camera head available in lengths of 65 or 100'
March 21, 2011 - Sony Electronics announced today that InterTest®, Inc, a supplier of specialized vision products, remote visual inspection (RVI) tools, and non-destructive testing (NDT) equipment, will be named an Authorized National Systems Integrator for Sony’s Visual Imaging Products division.
"Leveraging InterTest’s expertise with application specific packaging of Sony technology helps this new class of niche players speed products to market while lowering their development costs." – Bill Habermann, InterTest, Inc. President
iShot® XBlock® HD Cameras available in 3G-SDI, HD-SDI, USB 3.0, GigE, IP, HDMI. Private labeling available.
iShot® XBlock® SD Cameras available in USB 2.0, composite, built-in control pad, outdoor M-12 or purged.
